CPC(D)50L-100

5000-10000kg A Series IC Forklift

Specifikationer

Manufacturer's   type designation CPCD50L / CPCD60 / CPCD70 / CPCD85 / CPCD90 / CPCD100
Load capacity/rated load kg / 5000 / 6000 / 7000 / 8500 / 9000 / 10000
Service weight incl kg / 8500 / 9050 / 9700 / 12300 / 12700 / 13600
Lift height mm / 3000 / 3000 / 3000 / 3000 / 3000 / 3000
Fork dimensions     s/e/l(mm) / 55x150x1520 / 60x150x1520 / 65x150x1520 / 70x175x1670 / 70x175x1670 / 80x175x1670
Overall length（Including cargo fork）   mm / 5190 / 5190 / 5190 / 5710 / 5710 / 6070
Turning radius mm / 3350 / 3350 / 3350 / 3700 / 3700 / 3900
Travel speed,laden/unladen km/h / 26/28 / 26/28 / 25/28 / 26/28 / 26/28 / 26/28
Max.Gradient performance,laden/unladen S2  % / 25/20 / 25/20 / 25/20 / 21/20 / 21/20 / 21/20
Engine builder Mitsubishi   (Euro IIIA) / Mitsubishi     (Euro IIIA) / Mitsubishi     (Euro IIIA) / Isuzu    （EuroⅠ） / Isuzu    （EuroⅠ） / Isuzu    （EuroⅠ）
Service brake Hydraulic / Hydraulic / Hydraulic / Hydraulic / Hydraulic / Hydraulic


Se fullständig information hos Noblelift →

Produktbeskrivning

CPC(D)50L-100
CPC(D)50L-100
CPC(D)50L-100
CPC(D)50L-100

Denna sida uppdateras automatiskt utifrån Noblelifts produktsortiment.
